DH-60V100AH
Low-speed vehicle lithium battery

Model:DH-60V100AH

mAh:100AH

Cell

Dimensions:698*295*180(mm)

Use:Electric Low-Speed Vehicles

Products - Low-speed car lithium battery DH-60V100AH Low-speed vehicle lithium battery
Use:Electric Low-Speed Vehicles
DEHUA
Online
Introduction

Usage precautions

1, please use the manufacturer's matching national standard lithium battery charger to charge;

2, to charge in the set charging area, charging away from flammable materials;

3. Charging voltage, charging current and charging ambient temperature shall not be higher than the upper limit of parameters specified in this manual;

4, correctly connect the positive and negative terminals of the battery to avoid reverse connection;

5, prohibit the use of lithium batteries, do not short circuit lithium batteries;

6, when the battery is impacted by collision, fall, extrusion deformation, test and then use;

7, the use of lithium batteries should be away from fire, heat sources, to avoid direct sunlight;

8, can not privately the voltage, the internal assistant is not the same battery, series charging and use;

9. It is forbidden to disassemble the lithium battery and use sharp instruments to puncture the lithium battery;

10, once the lithium battery is on fire, the fire lithium battery is quickly buried in water or soil;

11, it is strictly prohibited to charge lithium batteries in the corridor or the house;

Transportation

1. No metal items are allowed above the lithium battery during transportation;

2, it is prohibited to mix with other items during transportation;

3, lithium battery less than 50% of the state transport

Store

1, lithium battery 50% power storage, supplement once a month, can extend the service life;

2, long-term storage of lithium batteries, should be placed in a dry, ventilated and cool place, the ambient temperature of 0~35℃ humidity 5%;

3. Lithium batteries are prohibited from being stored near fire sources and high temperatures;

4, storage lithium battery pay attention to moisture, waterproof, prevent water;

Peculiarity
  • High energy density

    The energy density of lithium batteries far exceeds that of other types of batteries, such as lead-acid batteries and nickel-metal hydride batteries. Under the same volume, the energy density of lithium batteries can reach 180-220Wh/Kg, or even higher.

  • High security

    Lithium battery has good thermal stability, is not easy to occur thermal fusion, and its internal resistance value is very small, can effectively prevent self-discharge, so as to achieve safe and reliable use.

  • Small size and light weight

    The volume and weight of lithium batteries are smaller than traditional batteries, which makes lithium batteries widely used in a variety of electronic devices, such as mobile phones, laptops, cameras, power tools and so on.

  • Charge and discharge speed is fast

    Lithium battery charging speed is fast, save time, can work normally between -20℃ ~ 60℃, adapt to various environmental conditions.

Specification


Model   specifications

DH-60V100AH


Cell type

Lithium iron   phosphate


Welding method

Laser welding


Capacity

100AH


Maximum power

7000W


Maximum   continuous operating current

120A


Supports maximum   fast charging stream

60A


Standard   charging current

10A-20A


Charge cut-off   voltage

73V


Low temperature   charge heating

There is no


Bluetooth meter



Mobile phone   Bluetooth

Scan the QR code   to download Xiaoxiang APP (available for Android) To see more battery   information on your phone





GPS

There is no


Comm 485

There is no


Communication   CNA

There is no


Service life

3,000 times


Energy

6400wh


Protection   features

Short circuit,   over current, over charge, over discharge, high temperature, low temperature,   under voltage, over voltage and other protection functions


Overcurrent/short   circuit protection recovery conditions

Charge or   disconnect load recovery


Waterproof class

IP65


Weight

49.7 kg


Battery pack   size

Dimensions: 698   x 295 x 180 (mm)



*Note: Products are constantly updated and upgraded. If the feature description and technical parameters differ from the actual product, the actual product shall prevail.
