48V 12AH orange hedge trimmer

Model:DH-LLJ-J-CY-1A-10-36V12AH

mAh:12AH

Cell:18650 2000mAH

Dimensions:320×240×90

Use:Special lithium battery for hedge trimmers

Gardening tool lithium battery - A type hedge trimmer 48V 12AH orange hedge trimmer
Use:Special lithium battery for hedge trimmers
DEHUA
Online
Introduction

Usage precautions

1, please use the manufacturer's matching national standard lithium battery charger to charge;

2, to charge in the set charging area, charging away from flammable materials;

3. Charging voltage, charging current and charging ambient temperature shall not be higher than the upper limit of parameters specified in this manual;

4, correctly connect the positive and negative terminals of the battery to avoid reverse connection;

5, prohibit the use of lithium batteries, do not short circuit lithium batteries;

6, when the battery is impacted by collision, fall, extrusion deformation, test and then use;

7, the use of lithium batteries should be away from fire, heat sources, to avoid direct sunlight;

8, can not privately the voltage, the internal assistant is not the same battery, series charging and use;

9. It is forbidden to disassemble the lithium battery and use sharp instruments to puncture the lithium battery;

10, once the lithium battery is on fire, the fire lithium battery is quickly buried in water or soil;

11, it is strictly prohibited to charge lithium batteries in the corridor or the house;

Transportation

1. No metal items are allowed above the lithium battery during transportation;

2, it is prohibited to mix with other items during transportation;

3, lithium battery less than 50% of the state transport

Store

1, lithium battery 50% power storage, supplement once a month, can extend the service life;

2, long-term storage of lithium batteries, should be placed in a dry, ventilated and cool place, the ambient temperature of 0~35℃ humidity 5%;

3. Lithium batteries are prohibited from being stored near fire sources and high temperatures;

4, storage lithium battery pay attention to moisture, waterproof, prevent water;

Peculiarity
  • High energy density

    The energy density of lithium batteries far exceeds that of other types of batteries, such as lead-acid batteries and nickel-metal hydride batteries. Under the same volume, the energy density of lithium batteries can reach 180-220Wh/Kg, or even higher.

  • High security

    Lithium battery has good thermal stability, is not easy to occur thermal fusion, and its internal resistance value is very small, can effectively prevent self-discharge, so as to achieve safe and reliable use.

  • Small size and light weight

    The volume and weight of lithium batteries are smaller than traditional batteries, which makes lithium batteries widely used in a variety of electronic devices, such as mobile phones, laptops, cameras, power tools and so on.

  • Charge and discharge speed is fast

    Lithium battery charging speed is fast, save time, can work normally between -20℃ ~ 60℃, adapt to various environmental conditions.

Specification

Product Parameters

Product model number

DH-LLJ-J-CY-1A-10-36V12AH


Product name

Lithium battery for   hedge machine


Battery cell

18650  2000mAH


Nominal voltage

48V


Battery capacity

12AH


Energy

577.2 Wh


Applicable motor power

48V  0-1200W


Suitable for continuous working current

0-30A


Continuous working hours (2A)

6 hours


Power display

Display current voltage


Display remaining power


Turn off automatically after 10 seconds of light


Battery self-protection function

Charge to 54.6V   automatic protection to prevent overcharging


Discharge to 36.4V   automatic protection to prevent overdischarge


Use automatic   overcurrent protection when the current exceeds 60A instantaneously


When improper protection is used, the disconnected load   automatically recovers


Internal Assistant

Fully charged 25C (77F)

26 m Ω


Service life

25 (77) 1C discharge 1000   times


Charge and Discharge Method 25
   (77
)

Charging

Charging current 1A-6A
   charger termination voltage 54.6V




Discharge

Maximum continuous   discharge current 30A
   Instantaneous maximum working current   60A
   overdischarge protection voltage   36.4VV






Package size

Battery size
   (L x W x H)

Mm ±1

320 * 240 * 90

inches


Package dimensions
   (L x W x H)

Mm ±2

510 * 390 * 270

inches


Quantity per box

4 pieces

Net weight per battery

4.8 kg + 100 g

Gross weight of batteries per box

20.2 kg



Battery material

Ingredients

Positive plate

Negative plate

Housing

Explosion-proof method

Dividers

Electrolyte

Ingredients

Ternary (nickel, cobalt, manganese)

Graphite

Nickel-plated steel shell

PDC cap + pull ring

Ceramic diaphragm

Lithium salt


*Note: Products are constantly updated and upgraded. If the feature description and technical parameters differ from the actual product, the actual product shall prevail.
