24V20AH Orange tea-picking machine

Model:DH-CCJ-J-CY-EE-7-24V20AH

mAh

Cell:18650 2000mAH

Dimensions:320×240×90

Use:Special lithium battery for tea-picking machines

Gardening tool lithium battery - A type tea harvester 24V20AH Orange tea-picking machine
Use:Special lithium battery for tea-picking machines
DEHUA
Online
24V20AH Orange tea-picking machine
Introduction

Usage precautions

1, please use the manufacturer's matching national standard lithium battery charger to charge;

2, to charge in the set charging area, charging away from flammable materials;

3. Charging voltage, charging current and charging ambient temperature shall not be higher than the upper limit of parameters specified in this manual;

4, correctly connect the positive and negative terminals of the battery to avoid reverse connection;

5, prohibit the use of lithium batteries, do not short circuit lithium batteries;

6, when the battery is impacted by collision, fall, extrusion deformation, test and then use;

7, the use of lithium batteries should be away from fire, heat sources, to avoid direct sunlight;

8, can not privately the voltage, the internal assistant is not the same battery, series charging and use;

9. It is forbidden to disassemble the lithium battery and use sharp instruments to puncture the lithium battery;

10, once the lithium battery is on fire, the fire lithium battery is quickly buried in water or soil;

11, it is strictly prohibited to charge lithium batteries in the corridor or the house;

Transportation

1. No metal items are allowed above the lithium battery during transportation;

2, it is prohibited to mix with other items during transportation;

3, lithium battery less than 50% of the state transport

Store

1, lithium battery 50% power storage, supplement once a month, can extend the service life;

2, long-term storage of lithium batteries, should be placed in a dry, ventilated and cool place, the ambient temperature of 0~35℃ humidity 5%;

3. Lithium batteries are prohibited from being stored near fire sources and high temperatures;

4, storage lithium battery pay attention to moisture, waterproof, prevent water;

Peculiarity
  • High energy density

    The energy density of lithium batteries far exceeds that of other types of batteries, such as lead-acid batteries and nickel-metal hydride batteries. Under the same volume, the energy density of lithium batteries can reach 180-220Wh/Kg, or even higher.

  • High security

    Lithium battery has good thermal stability, is not easy to occur thermal fusion, and its internal resistance value is very small, can effectively prevent self-discharge, so as to achieve safe and reliable use.

  • Small size and light weight

    The volume and weight of lithium batteries are smaller than traditional batteries, which makes lithium batteries widely used in a variety of electronic devices, such as mobile phones, laptops, cameras, power tools and so on.

  • Charge and discharge speed is fast

    Lithium battery charging speed is fast, save time, can work normally between -20℃ ~ 60℃, adapt to various environmental conditions.

Specification

Product Parameters

Product model   number

DH-CCJ-J-CY-EE-7-24V20AH


Product name

Lithium battery   for tea picker


Battery

18650  2000mAH


Nominal voltage

24V


Battery capacity

20AH


Energy

24V  518Wh


Applicable motor   power

0-400W


Apply continuous   working current

0-10A


Consecutive   working hours (2A)

10 hours


Power display

Display current   voltage


Display   remaining power


Turn off   automatically after 10 seconds


Battery   self-protection function

Charge to 29.4V   automatic protection to prevent overcharging


Discharge to   19.6V automatic protection to prevent overdischarge


Automatic   overcurrent protection when the current exceeds 10A instantaneously


When improper   protection is used, the disconnected load automatically recovers


Internal   Assistant

Fully charged   25C (77F)

26 m Ω


Service life

25 (77) 1C discharge 1000 times


Charge and   Discharge Method 25
   (77
)

Charging

Charge current   1A-10A
   charger termination voltage 29.4V




Discharge

Maximum   continuous discharge current 10A
   Maximum instantaneous working current   10A
   overdischarge protection voltage 19.6V






Package size

Battery size
   (L x W x H)

Mm ±1

320 * 240 * 90

inches


Package   dimensions
   (L x W x H)

Mm ±2

510 * 390 * 270

inches


Quantity per box

4 pieces

Quantity per box

4.4 kg + 100 g

Gross weight of   batteries per box

18.42 kg

Battery material

ingredient

Positive plate

Negative plate

Housing

Explosion-proof   method

Dividers

Electrolyte

Ingredients

Ternary (nickel,   cobalt, manganese)

Graphite

Nickel-plated   steel shell

PDC cap + pull   ring

Ceramic   diaphragm

Lithium salt


*Note: Products are constantly updated and upgraded. If the feature description and technical parameters differ from the actual product, the actual product shall prevail.
