GX150-60-150(B)
Lithium battery for electric vehicles

Model:DH-60V150Ah

mAh:150Ah

Cell:3.2V150AH

Dimensions:758*325*220mm

Use:Special for electric flatbed carts

Electric vehicle lithium battery - 60-150 GX150-60-150(B) Lithium battery for electric vehicles
Use:Special for electric flatbed carts
DEHUA
Online
Introduction

Usage precautions

1, please use the manufacturer's matching national standard lithium battery charger to charge;

2, to charge in the set charging area, charging away from flammable materials;

3. Charging voltage, charging current and charging ambient temperature shall not be higher than the upper limit of parameters specified in this manual;

4, correctly connect the positive and negative terminals of the battery to avoid reverse connection;

5, prohibit the use of lithium batteries, do not short circuit lithium batteries;

6, when the battery is impacted by collision, fall, extrusion deformation, test and then use;

7, the use of lithium batteries should be away from fire, heat sources, to avoid direct sunlight;

8, can not privately the voltage, the internal assistant is not the same battery, series charging and use;

9. It is forbidden to disassemble the lithium battery and use sharp instruments to puncture the lithium battery;

10, once the lithium battery is on fire, the fire lithium battery is quickly buried in water or soil;

11, it is strictly prohibited to charge lithium batteries in the corridor or the house;

Transportation

1. No metal items are allowed above the lithium battery during transportation;

2, it is prohibited to mix with other items during transportation;

3, lithium battery less than 50% of the state transport

Store

1, lithium battery 50% power storage, supplement once a month, can extend the service life;

2, long-term storage of lithium batteries, should be placed in a dry, ventilated and cool place, the ambient temperature of 0~35℃ humidity 5%;

3. Lithium batteries are prohibited from being stored near fire sources and high temperatures;

4, storage lithium battery pay attention to moisture, waterproof, prevent water;

Peculiarity
  • High energy density

    The energy density of lithium batteries far exceeds that of other types of batteries, such as lead-acid batteries and nickel-metal hydride batteries. Under the same volume, the energy density of lithium batteries can reach 180-220Wh/Kg, or even higher.

  • High security

    Lithium battery has good thermal stability, is not easy to occur thermal fusion, and its internal resistance value is very small, can effectively prevent self-discharge, so as to achieve safe and reliable use.

  • Small size and light weight

    The volume and weight of lithium batteries are smaller than traditional batteries, which makes lithium batteries widely used in a variety of electronic devices, such as mobile phones, laptops, cameras, power tools and so on.

  • Charge and discharge speed is fast

    Lithium battery charging speed is fast, save time, can work normally between -20℃ ~ 60℃, adapt to various environmental conditions.

Specification



Items

Parameters

Remarks


Battery model

DH-60V150Ah



Cell model number

3.2 V150AH



Nominal voltage

64V



Nominal capacity

150Ah

0.5 C, 25


Energy

9600kwh



Combination way

20S1P



Battery materials

Lithium iron phosphate


Electric Discharge

Working current

120A


Maximum current

360A

< 2S

Cut-off voltage

50V


charging

Charging voltage

73V


Maximum current

25A


Charging mode

Constant current/constant voltage

CC/CV

Charging cutoff current

About 0.02C5A

CC/CV

Operating temperature

Charging temperature

0 to + 45

At60±25%RH environment is greater than 45, pay attention to ventilation and heat dissipation

Discharge temperature

- 10 - + 55

Greater than 60% is pay attention to waterproof

Charge and discharge humidity

RH60%



Protective features

Over charge protection, over discharge protection, over current protection, short circuit protection



Weight




Measurements

758*325*220mm



Smart features

Bluetooth, GPS, RS485, CAN, one-click strong start, reservation heating, etc

Customizable options are available as needed


*Note: Products are constantly updated and upgraded. If the feature description and technical parameters differ from the actual product, the actual product shall prevail.
