Model:DH-24V20AH
mAh:20AH
Cell:18650 2000mAH
Dimensions:320×240×90(mm)
Use:Lithium batteries for garden tools
Model:DH-24V20AH
mAh:20AH
Cell:18650 2000mAH
Dimensions:320×240×90(mm)
Use:Lithium batteries for garden tools
Usage precautions
1, please use the manufacturer's matching national standard lithium battery charger to charge;
2, to charge in the set charging area, charging away from flammable materials;
3. Charging voltage, charging current and charging ambient temperature shall not be higher than the upper limit of parameters specified in this manual;
4, correctly connect the positive and negative terminals of the battery to avoid reverse connection;
5, prohibit the use of lithium batteries, do not short circuit lithium batteries;
6, when the battery is impacted by collision, fall, extrusion deformation, test and then use;
7, the use of lithium batteries should be away from fire, heat sources, to avoid direct sunlight;
8, can not privately the voltage, the internal assistant is not the same battery, series charging and use;
9. It is forbidden to disassemble the lithium battery and use sharp instruments to puncture the lithium battery;
10, once the lithium battery is on fire, the fire lithium battery is quickly buried in water or soil;
11, it is strictly prohibited to charge lithium batteries in the corridor or the house;
Transportation
1. No metal items are allowed above the lithium battery during transportation;
2, it is prohibited to mix with other items during transportation;
3, lithium battery less than 50% of the state transport
Store
1, lithium battery 50% power storage, supplement once a month, can extend the service life;
2, long-term storage of lithium batteries, should be placed in a dry, ventilated and cool place, the ambient temperature of 0~35℃ humidity 5%;
3. Lithium batteries are prohibited from being stored near fire sources and high temperatures;
4, storage lithium battery pay attention to moisture, waterproof, prevent water;
The energy density of lithium batteries far exceeds that of other types of batteries, such as lead-acid batteries and nickel-metal hydride batteries. Under the same volume, the energy density of lithium batteries can reach 180-220Wh/Kg, or even higher.
Lithium battery has good thermal stability, is not easy to occur thermal fusion, and its internal resistance value is very small, can effectively prevent self-discharge, so as to achieve safe and reliable use.
The volume and weight of lithium batteries are smaller than traditional batteries, which makes lithium batteries widely used in a variety of electronic devices, such as mobile phones, laptops, cameras, power tools and so on.
Lithium battery charging speed is fast, save time, can work normally between -20℃ ~ 60℃, adapt to various environmental conditions.
Product model number | DH-LLJ-J-CY-1A-7-24V20AH | |||
Product name | Lithium battery for hedge machine | |||
cell | 18650 2000mAH | |||
Nominal voltage | 24V | |||
Battery capacity | 20AH | |||
Energy | 518Wh | |||
Applicable motor power | 24V 0-800W | |||
Apply continuous working current | 0-30A | |||
Continuous working hours (2A) | 10 hours | |||
Power display | Display current voltage | |||
Display remaining power | ||||
Turn off automatically after 10 seconds of light | ||||
Battery self-protection function | Charge to 29.4V automatic protection to prevent overcharging | |||
Discharge to 19.6V automatic protection to prevent overdischarge | ||||
Use automatic overcurrent protection when the current exceeds 60A instantaneously | ||||
When improper protection is used, the disconnected load automatically recovers | ||||
Internal Assistant | Fully charged 25C (77F) | 26 m Ω ≦ | ||
Service life | 25℃ (77℉) ≦1C discharge 1000 times | |||
Charge and Discharge Method 25℃ | Charging | Charge current 1A-10A | ||
Discharge | Maximum continuous discharge current 30A | |||
Product parameters
Package size
Battery size | Mm ±1 | 320 * 240 * 90 |
inches | ||
Package dimensions | Mm ±2 | 510 * 390 * 270 |
inches | ||
Quantity per box | 4 pieces | |
Net weight per battery | 4.4 kg + 100 g | |
Gross weight of batteries per box | 18.42 kg |
Cell material
Ingredients | Positive plate | Negative plate | Housing | Explosion-proof method | Dividers | Electrolyte |
Ingredients | Ternary (nickel, cobalt, manganese) | Graphite | Nickel-plated steel shell | PDC cap + pull ring | Ceramic diaphragm | Lithium salt |
